End Mill Double-Flute (Flat) Ø 2 mm downcut
Technical Specifications:
- Solid Carbide-End Mill Ø 2 mm
- Double-Flute
- Flat Bottom
- Downcut-spiral
- D2 (Shank): 3.175 mm (1/8")
- SL (Spiral length): 8 mm
- NL (Usable Spiral length) = 0,85 x Spiral length
- GL (Overall length): 38 mm
Characteristics
- Industrial Quality
- Low wear through Flat Bottom
- Flat Bottom for very clean surfaces in pockets
Applications
- universally applicable
- Aluminium
- Plastics
- Wood
Notes:
- Further diameters and spiral lengths on request.
- Left spiral and/or left cutting mills on request.
Manufacturer: | Responsible person: |
| Safety instructions: | ||
 | 1. | Always read and observe the safety instructions and warnings in the available documents. |
| 2. | The installation, commissioning and operation require special knowledge of machines and their proper operation, as well as basic knowledge of electrical engineering. The instructions - including those in the descriptions - must be followed carefully. | |
| 3. | The location where machines are operated must ensure that unauthorized persons - especially children - do not have access without adequate supervision. | |
| 4. | The use of kits / components usually requires additional measures and additions. | |
