cncGraF 7.1

... is a CNC control software for machines up to 5 axes. It is controlled by the smc5d CNC controller.

cncGraF 7.1 is currently available in 3 versions:

Lite with restrictions (e.g. without saving and without DXF import), but fully functional on three axis.
Standard supports CNC machines up to four axes.
Professional supports machines up to five axes and, in addition to an expanded range of functions, also offers pro features such as support for tool changers, double-axis drive (Z2), scanning functions, etc.

The professional version can also be greatly customized through the use of macros and, if necessary, can also be expanded through the integration of third-party plugins.
An upgrade from Lite or Standard to Professional can be carried out at any time via BOENIGK.​

Here are the differences listed in detail.
Aluminium housing for SMC5D-p32
22,00 EUR

incl. 19% tax excl. Shipping costs
CNC-Graf I/O Expansion for SMC5D-m4 pro
CAN-Communication
16 Inputs / 20 Outputs, incl. connection cable
499,80 EUR

incl. 19% tax excl. Shipping costs
CNC-Graf DAC 0 ... 10 V Expansion for SMC5D-m4
For speed control of the milling spindle via a frequency converter
345,10 EUR

incl. 19% tax excl. Shipping costs
CNC-Graf interface card DAC-INT-10V
Extension for SMC5D
For speed control of the milling spindle via a frequency converter
95,20 EUR

incl. 19% tax excl. Shipping costs
CNC-Graf Electronic Handwheel
464,00 EUR

incl. 19% tax excl. Shipping costs
1 to 9 (from a total of 9)
